#503    Insulating Strip, 3 hole............$ 1.04

#507    Insulating Flat Girder, 5 hole......$ 3.06

#508    Insulating Flat Girder, 3 hole......$ 1.88

#510    Insulating Plate, 11 x 5 hole.......$14.39

#511    Insulating Plate, 5 x 5 hole........$ 7.12

#513    Insulating Fishplate................$  .82

#518    Bush Wheel, 1”......................$ 3.61

#525    Core Holder for Rectangular Coil....$ 2.94

#527    Core for Cylindrical Coil, slotted..$ 3.89

#528    Core for Cylindrical Coil, threaded.$ 3.89

#532    Wiper Arm, 1 1/2” radius, flexible..$ 1.23

#533    Wiper Arm, 2" radius................$ 6.02

#538    Magnet Holder.......................$ 6.42

#539    Lamp Holder.........................$ 4.82

#544    Contact Stud........................$ 1.33

#545    Pivot Bolt..........................$ 3.00

#548    Pivot Rod, 3 1/2”...................$ 2.44

#549    Pivot Rod, 2”.......................$ 2.27

#550    Short Pivot.........................$ 1.45

#551    Flat Commutator.....................$14.95

#555    Rod with square end, 4”.............$ 4.13

#601    MO MK I 6 volt Motor w/o casing.....$ 7.50

#606    Relay...............................$25.00

#608    Lamp, 12 volt.......................$ 1.50

#612    Miniature Plug......................$ 1.00

#620    Battery Control Box.................$25.00

#P91    Caterpillar Track Link..............$  .89



HEAVY DUTY SYSTEM FOR 5/16”, 8MM DIAMETER AXLES:

#19D 3” Pulley, w/o boss....................$ 7.24

#20C 2” Pulley, w/o boss....................$ 5.24

#21A 1 1/2” Pulley w/o boss.................$ 4.96

#62E Short Arm Crank, w/o boss..............$ 1.17

#62F Double Arm Crank, w/o boss.............$ 1.15

#62G Crank, w/o boss........................$ 1.13

#A251 4” Toothed Disc, 152 teeth............$27.93

#251A 3 1/2” Toothed Disc, 133 teeth........$20.82

#251B 2 1/2” Toothed Disc, 95 teeth.........$10.45

#251C 1 3/4” Toothed Disc, 65 teeth.........$ 6.11

#251D 1 5/8” Toothed Disc, 60 teeth.........$ 5.16

#251E 1 1/2” Toothed Disc, 57 teeth.........$ 4.86

#251F 1 7/16” Toothed Disc, 55 teeth........$ 4.57

#251G 1 3/8” Toothed Disc, 50 teeth.........$ 3.88

#252 Sq Bearing Plate/boss, 1 1/2” x 1 1/2”.$ 7.88

#252A Pillow Block, Ball Bearing set of 2...$15.75

#253 Bush Wheel, 1 3/8” diam. 8 hole....... $ 6.89

#253A Bush Wheel, 1 3/8” diam. 6 hole.......$ 6.89

#253B Bush Wheel, 1 3/8” diam. 5 hole.......$ 6.89

#253C Bush Wheel, Heavy Duty 1/2” thick.....$ 4.26

#254 Collar, 1/2” diam. x 3/8” long.........$ 2.61

#254A Narrow Collar, 1/2” diam. x 1/4” long.$ 2.21

#255 Coupling, 15/16” long x 5/8” diam......$ 8.99

#255A Adapter Coupling, Large<>Standard.....$14.11

#255B Oldham Coupling.......................$24.20

#255C Dog Clutch...............................$16.11

#255D Universal Joint..........................$34.30

#256 Axle Rod, 8” long.........................$13.52

#256A Axle Rod, 6 1/2” long....................$11.02

#256B Axle Rod, 5 1/2” long....................$ 9.32

#256C Axle Rod, 3 1/2” long....................$ 5.92

#257 Washer, 1/2” O.D..........................$  .55

#258 Hollow Axle, 2” long, 0.165” I.D..........$ 4.91

#258A Hollow Axle, 1” long, 0.165” I.D.........$ 3.64

#258B Hollow Axle, 3” long, 0.165” I.D.........$ 8.53

#258C Hollow Axle, 4” long, 0.165” I.D.........$ 8.77

#258D Hollow Axle, 6” long, 0.165” I.D.........$12.54

#258E Hollow Axle, 8” long, 0.165” I.D.........$16.33

#258F Hollow Axle, Cross Tapped 3” long........$10.03

#259  Sprocket Wheel 3/4”, 14 teeth............$ 8.56

#259A Sprocket Wheel 1”, 18 teeth..............$ 8.39

#259B Sprocket Wheel 1 1/2”, 28 teeth..........$ 9.36

#259C Sprocket Wheel 2”, 36 teeth..............$12.18

#259D Sprocket Wheel 3”, 56 teeth..............$14.76



Formed Cylindrical Girders:

#261B Formed Cylindrical Girder, 1/2”r 5 h.....$ 1.41

#261F Formed Cylindrical Girder, 1/2”r 11h.....$ 2.33

#261K Formed Cylindrical Girder, 1/2”r 19 h....$ 4.15

#262 Formed Fishplate, 1/2”r...................$  .32

#262A Formed Angle Bracket, 1/2”r..............$  .39

#263 End Cap for 261’s, 1 1/16” (27 mm) ID.....$ 3.40



*Note: Above Cylinders are formed 3 to the circle



#270B Formed Cylindrical Girder, 1”r 5 hole....$ 1.41

#270F Formed Cylindrical Girder, 1”r 11 h......$ 2.33

#270K Formed Cylindrical Girder, 1”r 19 h....Sold Out

#271 Formed Fishplate, 1”r.....................$  .32

#271A Formed Angle Bracket, 1”r................$  .39

#137(A) End Cap for 270’s......................$ 5.59



*Note: Above Cylinders are formed 6 to the circle



Special Narrow Strips:

#273 Narrow Curved Strip, 5 hole, 4” radius....$ 1.43

#273A Narrow Curved Strip, 7 hole, 6” radius...$ 1.69

#273B Narrow Curved Strip, 9 hole, 8” radius...$ 1.93

#273C Narrow Curved Strip, 11 hole, 10” radius.$ 2.41

#273D Narrow Curved Strip, 13 hole, 12” radius.$ 2.96

#273E Narrow Curved Strip, 15 hole, 14” radius.$ 3.25

#275A Narrow Angle Girder, 1 1/2” 3 hole.......$ 1.09

#275B Narrow Angle Girder, 2” 4 hole...........$ 1.38

#275C Narrow Angle Girder, 2 1/2” 5 hole.......$ 1.61

#275D Narrow Angle Girder, 3” 6 hole...........$ 1.86

#275E Narrow Angle Girder, 3 1/2” 7 hole.......$ 2.13

#275G Narrow Angle Girder, 4 1/2” 9 hole.......$ 2.48

#275H Narrow Angle Girder, 5 1/2” 11 hole......$ 3.36

#275J Narrow Angle Girder, 6 1/2” 13 hole......$ 3.96

#275K Narrow Angle Girder, 7 1/2” 15 hole......$ 4.58

#275M Narrow Angle Girder, 9 1/2” 19 hole......$ 5.78

#275Q Narrow Angle Girder, 12 1/2” 25 hole.....$ 7.53

#280  Narrow Flat Girder, 1 1/2” 3 hole........$ 1.09

#280A Narrow Flat Girder, 2” 4 hole............$ 1.38

#280B Narrow Flat Girder, 2 1/2” 5 hole........$ 1.61

#280C Narrow Flat Girder, 3” 6 hole............$ 1.86

#280D Narrow Flat Girder, 3 1/2” 7 hole........$ 3.20

#280E Narrow Flat Girder, 4 1/2” 9 hole........$ 2.76

#280F Narrow Flat Girder, 5 1/2” 11 hole.......$ 3.36

#280G Narrow Flat Girder, 6 1/2” 13 hole.......$ 3.96

#280H Narrow Flat Girder, 7 1/2” 15 hole.......$ 4.58

#280K Narrow Flat Girder, 9 1/2” 19 hole.......$ 5.78

#280H Narrow Flat Girder, 12 1/2” 25 hole......$ 7.53

#1011 Channel Girder 1 x 3 x 1 hole, 5 1/2”....$ 7.75

#1025 Channel Girder 1 x 3 x 1 hole, 12 1/2”...$17.64

Meccano Key Chain..............................$14.95

Meccano Name Plate, 13 1/2” Red or Yellow......$ 9.50

Meccano Name Plate, 6 1/2” Red or Yellow.......$ 6.15

Meccano Name Plate, 4 1/2” Red, Yellow or Blue.$ 5.00

Meccano Pennant, 5” Red or Yellow..............$ 6.00



“X” Series Parts:

X404 Perforated Strip, 5 1/4” Long.............$ 3.22

X405 Perforated Strip, 4 1/4” Long.............$ 2.59

X407 Perforated Strip, 2 3/4” Long.............$ 1.79

X409 Perforated Strip, 1 3/4” Long.............$ 1.36

X421 Angle Bracket, 1/2” x 1/2”................$  .97

X455 Double Angle Strip, 1 3/4” x 1/2”.........$ 2.02

X457 Double Angle Strip, 3/4” x 1/2”...........$ 1.69

X475 Disc, 3/4”................................$ 2.13
